Beaver B Safe 22kN Stainless Steel Concrete Anchor M16 with 150mm thread

Availability: In stock
Vendor: Beaver Brands
SKU: BSL5008A
B-SAFE 316 GRADE STAINLESS STEEL ANCHOR POINTS Rated at 22kN B-Safe anchor point. Affording quick and easy installation, B-Safe Anchors are suitable for commercial, industrial and residential applications. It is...
$39.95
$39.95
$39.95
Save $0.00
Beaver B Safe 22kN Stainless Steel Concrete Anchor M16 with 150mm thread

Beaver B Safe 22kN Stainless Steel Concrete Anchor M16 with 150mm thread

$39.95
Beaver B Safe 22kN Stainless Steel Concrete Anchor M16 with 150mm thread

Beaver B Safe 22kN Stainless Steel Concrete Anchor M16 with 150mm thread

$39.95
Description
Description
x

B-SAFE 316 GRADE STAINLESS STEEL ANCHOR POINTS

Rated at 22kN B-Safe anchor point. Affording quick and easy installation, B-Safe Anchors are suitable for commercial, industrial and residential applications. It is important to ensure the structure, to which any anchor is installed, has sufficient strength (refer AS/NZS 1891.4) to sustain the applied load.

BSL5008 Concrete Anchor 16mm with 150mm thread length (not supplied with chemical).

All safety procedures must be complied with in accordance with the current safety code(s) of practice(s) for working at heights. Ensure safety at all times during and after installation by using an appropriate height safety system.

The B Safe Anchor Point must be in a position easily and safely reached from a safe access point. -

B Safe should not be positioned close to an edge, minimum distance 150mm. - Minimum concrete thickness 100mm.

If any doubt exists with the strength of the structure or roof sheets an engineer should make the assessment.

Installation must be carried out by, or under the supervision of a competent person

During installation you must be safe at all times.

DRILLING THE HOLE

Drill a 18mm hole to a depth of 150mm.

PREPARING THE HOLE

The hole must be moisture and dust free.

Remove dust using compressed air, small brush and vacuum cleaner.

INSTALLING

Recommended chemical anchor: Hilti RE500 or Hilti HY200 as per Hilti Product Supplement Data sheets.

Read instructions on product carefully. Use sufficient adhesive gel as specified on the product instructions.

Testing for Free fall-arrest for one person. 15 kN ultimate strength.

To comply with current Standards each Concrete Anchor unit must be tested after installation. Allow sufficient time at least 48 hours for curing before testing. Test consists of ultimate pull out force proof loading to 50% of design purpose of anchorage. Note: Drilled-in anchorages such as friction and glued-in anchorages shall be placed so that the shear load is at least twice the tension load. For collared eyebolts this translates to a pull at an angle not exceeding 20 degrees to the surface in which the bolt is installed.
